SOKKIA GHX2
The GHX2 network rover system is an all-in-one handheld GNSS receiver and field controller featuring high-speed processor, increased memory, cellular modem, built-in camera, Bluetooth®, and Wi-Fi.
Using touchscreen technology, the GHX2 features direct touch access to all graphic controls. This 5.7 in. display is the main selling feature, while the Windows® Embedded Handheld 6.5 Professional OS provides a modern operating environment and added expandability with other application software. Graphical icon functionality allows for quick and easy operation. The fast 806MHz processor drives any MAGNET® field application software with ease.
With the addition of a built-in 3.2MP camera, 3.5G cellular modem and Bluetooth® / Wi-Fi capability, the GHX2 network rover system is an essential addition to any surveyor’s arsenal. Both Bluetooth® and Wi-Fi are standard features eliminating the need for expensive upgrades. The Sokkia GHX2 has dual hot-swappable batteries capable of up to 16 hours of operation. Additional accessories such as a dashboard mount and external battery charger are available to fit your needs.
Informazioni aggiuntive
| Marca | SOKKIA |
|---|---|
| Modello | GHX2 |
| PERFORMANCE | – |
| N. canali | 72 |
| Numero max di satelliti tracciati simultaneamente | – |
| Segnali satellitari tracciati | GPS / GLONASS |
| RTK | SI |
| Frequenza posizionamento | – |
| PRECISIONE | – |
| Statico rapido orizzontale | – |
| Statico rapido verticale | – |
| Statico preciso orizzontale | 3 mm + 0,5 ppm |
| Statico preciso verticale | 4 mm + 1 ppm (rms) |
| Cinematico RTK orizzontale | 10 mm + 1 ppm |
| Cinematico RTK verticale | 15 mm + 1 ppm |
| DATI | – |
| Memoria | Flash interna + SD |
| Capacità | 4 GB |
| COMUNICAZIONI | – |
| Porte | USB/Seriale/Alimentazione |
| Bluetooth | v2.0 + EDR, classe 1 |
| WiFi | 802.11 b/g |
| Radio UHF | – |
| Modulo GSM/GPRS | Penta-band 3.5G GSM/GPRS/EDGE/HSDPA 850/900/1800/1900/2100 MHz |
| ALIMENTAZIONE | – |
| Batteria interna | N.D. |
| Alimentazione esterna | N.D. |
| Autonomia aliment. Interna | 6 h |
| OPERATIVITÀ | – |
| Protezione IP | IP67 |
| Temperatura d'esercizio | da –30°C a +60°C |
| Umidità | – |
| Resistenza agli urti e vibrazioni | Resistente a cadute da 1.2 m di altezza su superfici dure |
| CARATTERISTICHE FISICHE | – |
| Altezza | 136 mm |
| Larghezza | 220 mm |
| Profondità | 51 mm |
| Diametro | – |
| Display | 5,7" VGA (640 x 480) |
| Peso | N.D. |
